C-RAY® ROV

C-RAY® ROV, is a patented high-pressure cleaning module,
mounted on a specially designed ROV

Bravo Marine’s C-RAY is designed for cleaning offshore structures. The C-Ray is an underwater cleaning machine that uses water and high pressure to remove all types of marine growth. Its unique shape makes it possible to reach and clean narrow, hard-to-access areas.

Unlike traditional cleaning methods, the C-RAY automatically adjust to the structure it is placed against, allowing ut to clean both pipes and flat surfaces underwater in a fast, environmentally firedly, and cost-effective way.

The system is capable of full 360° maneuverability, allowing operation in any direction and providing access to areas that are difficult to reach using conventional cleaning methods.

For complex geometries, C-RAY® can be equipped with a dedicated cleaning lance, enabling access to confined areas and supporting near-complete cleaning coverage of offshore structures.

Designed to Clean Complex Geometries

  • All pipe Diameters
  • Anodes
  • Guide Buckets
  • Risers
  • Conductors
  • Nodes and structural intersections
  • Flat surfaces
  • Complex offshore geometries

Technical Overview

  • Dimensions (L × W × H): 1752 × 1501 × 733 mm
  • Weight: 350kg
  • Design Water Depth: 300m
  • Operating Current: Up to 2,5 knots
  • Cleaning Pressure: Up to 1000 bar
  • Pressure Adjustment: Real-time control by ROV pilot
  • Mobility: Full 360° maneuverability
  • Compact offshore cleaning system
  • Full 360° maneuverability
  • Real-time pressure adjustment
  • ROV pilot controlled operation
  • Suitable for subsea infrastructure cleaning
  • Designed for offshore mobilisation

Intrested in what we do?

If you want to know more about what we do and our services, contact us directly.

Contact

C-RAY® ROV, is a

patented high-pressure

cleaning module,mounted on a specially designed ROV

With frequent cleaning of submerged infrastructure such as floating collars, sinker tubes, mooring ropes, chains and feed barges, the level and speed of biofouling growth on the nets will decrease. The frequency of net cleaning can be brought down, which leads to significant cost savings.

A cleaner marine environment improves fish welfare and reduces the costs related to fish mortality.

Significant cost reduction compared to current cleaning methods. More efficient use of company assets, low operating costs

Better working conditions (ROV pilot), safer operation.
